Compatible replacements · CV steel, resharpenable · from 1 piece
Saw blades for tree saws and lamier heads compatible with COUP'ECO and other makers
Tree saws and lamier heads on excavators, tractors or telehandlers clear field tracks, forest edges and hedges with several large circular saw blades. WSH-Tools.de in Germany makes matching saw blades from chrome vanadium steel, compatible with COUP'ECO machines and many other makers: to your sample, your dimensions or the part number.
Request a quote Send a photo via WhatsApp
Write to us – a photo of the blade with a tape measure is enough to start. We answer in German and English, via WhatsApp in other languages too.
- Ø 500 to 900 mm
- Bore and pin holes to fit
- Tooth form like the original
- Resharpenable
Dimensions we know
Ø 650 mm
80 teeth, 4 mm thick, 45 mm bore, 2 pin holes Ø 18 mm on a 120 mm pitch circle, max. 2,000 rpm.
Ø 700 mm
80 teeth, 4 mm thick. COUP'ECO part number 35.600.780. Bore and pin holes to sample.
Ø 500, 600 and 900 mm
For other machine models. Teeth, thickness, bore and pin holes to sample or dimensions.
Your blade has other dimensions? Send us the dimensions or a photo – write to us.
Example COUP'ECO: compatible with these machines
Meteor T90C
Lamier for telehandlers and front loaders, 3 or 4 blades Ø 600 mm.
Meteor P180
Lamier for excavators, 4 or 5 blades Ø 700 mm or 1 to 2 blades Ø 900 mm.
Cosmos 105T
Tree saw with 6 or 7 blades Ø 500 mm.
Other models such as Meteor P90, P360, MD100 or T90R on request: what matters are the dimensions of your blade. Model data from the maker's public product pages, without guarantee.
How we make your saw blade
Chrome vanadium (CV)
One piece, tough and elastic: takes knocks from branches and stones better than a brittle blade.
Tooth form like the original
Number of teeth, pitch, tooth height and rake angle taken from the sample.
Bore and pin holes
Fitted to shaft and flange so the blade runs smoothly without wobble.
Straightened and tensioned
Flatness and run-out checked before delivery to protect bearings and drive.
Compatible with tree saws of other makers
Rousseau (France)
Lamier, Ø 600 to 950 mm
Noremat (France)
Lamier Lineo, Ø 700 mm
SaMASZ (Poland)
Branch saw PT3 and PT4, Ø 630 mm
GreenTec (Denmark)
Quadsaw LRS, Ø 400 to 700 mm
Fliegl (Germany)
WoodKing, Ø 700 mm
Jansen
Branch saw AS-600, Ø 600 mm, 80 teeth
Fehrenbach (Germany)
Hedge cutter with circular saw blades
FEMAC (Italy)
Saw bar BD2 to BD4, Ø 600 mm
Tifermec (Italy)
Branch cutter, Ø 500 mm
We make blades for tree saws, lamier heads, verge and hedge cutters with circular saw blades for machines of these and other makers, to sample or dimensions. Machine data comes from public sources without guarantee; the dimensions of your blade are what counts. Write to us.
Your quote in three steps
- Send the dimensions. Diameter, thickness, bore, pin holes and number of teeth, by the form or via WhatsApp.
- Add a photo or the part number. The number engraved on the blade, a photo with a tape measure or the machine model help us check. On request we measure your sample blade.
- Receive your quote. We give you price and delivery time after checking.
Frequently asked questions
Do you make saw blades compatible with COUP'ECO machines?
Yes. We make compatible saw blades for COUP'ECO tree saws and lamier heads to sample, dimensions or part number, for example Ø 650 mm with 80 teeth, 4 mm thick, 45 mm bore and two pin holes Ø 18 mm on a 120 mm pitch circle. They are compatible replacements made by WSH-Tools.de, not original parts.
What information do you need for a quote?
Outside diameter, number of teeth, thickness, bore and pin holes with pitch circle. Plus the machine (for example Meteor or Cosmos), the number of blades and the maximum speed. The number engraved on the blade and a photo with a tape measure help.
Do you know the COUP'ECO part numbers?
Part number 35.600.780 is a saw blade Ø 700 mm with 80 teeth, 4 mm thick. Just give us the number from your blade or parts list; we assign it and check the dimensions.
What material are the blades made of?
As standard chrome vanadium steel (CV) in one piece. CV blades are tough, elastic and can be resharpened again and again. Carbide-tipped blades on request.
Can I resharpen the blades myself?
Yes, on your usual sharpening machine. We also resharpen your blades for you, including straightening and tensioning.
What speed are the blades rated for?
We design the blade for the maximum speed of your machine, for example 2,000 rpm. Please give us the speed from the type plate or manual.
Which diameters are possible?
We make them to sample, including Ø 500, 600, 650, 700 and 900 mm. Multi-blade heads mostly use 600 or 700 mm, single blades up to 900 mm.
Do the blades fit tree saws of other makers?
Yes. To sample we also make saw blades for machines of other makers, for example Rousseau, Noremat, SaMASZ, GreenTec, Fliegl, Jansen, Fehrenbach, FEMAC or Tifermec. What counts are the dimensions of your blade.
What is the minimum quantity?
One blade. For a complete set, for example four or five blades for a multi-blade head, and for your annual needs we gladly quote graduated prices.
Is WSH-Tools.de a partner of COUP'ECO or the other makers?
No. COUP'ECO and the other brands named belong to their respective owners. WSH-Tools.de is not affiliated with these makers; we name the brands only to state which machines our compatible saw blades fit.
Your question is not listed?
Write to us – we are happy to advise you and give you price and delivery time.
COUP'ECO and all other brands and product names on this page belong to their respective owners. WSH-Tools.de is not affiliated with these makers and is not a dealer. We name them only to state which machines our saw blades fit. These are compatible replacements made by WSH-Tools.de, not original parts.
